Generate accurate 2D patterns, optimize material usage, and export production-ready files — a comprehensive CAD/CAM solution for footwear pattern design.
With Crispin’s 2D Pattern Engineering tools, you can convert shoe designs into precise graded patterns, optimize fabric/ leather usage, output multiple formats for cutting — perfect for factories, sample rooms & small/large footwear brands.
Key Features
High-precision 2D Pattern Creation for uppers & soles
Automatic Grading & Size Range Support
Marker Making & Nesting for Material Optimization
Manual & Auto Pattern Adjustment / Editing Tools
Support for Custom Last & Shoe Styles
Accurate Seam Allowance & Stitch/Offset Controls
Export Patterns in DXF, PLT, AI, PDF (for cutting, plotting & production)
Compatible with CNC cutters, cutting-plotters, and manual cutting tools
Benefits
Save time and reduce manual errors during pattern making
Efficient material usage — less waste, lower cost
Fast pattern generation even for multiple sizes
Production-ready output — ready for cutting/machining/plotting
Seamless integration with 3D modeling & full CAD/CAM workflow (if used together)
Who Uses This
Footwear Manufacturers & Sample Departments
Pattern Makers & Shoe Factories
Custom Shoe Brands & Startups
Designers & Production Engineers
Workflow
Import or define shoe outline / last & design specs
Draw upper & sole patterns in 2D
Grade patterns for multiple sizes / size range
Adjust seams, offsets, stitch lines & allowances
Arrange pieces optimally (marker making / nesting)
Export final patterns in production-ready formats
What Crispin Provides
Complete 2D Pattern Engineering module in footwear CAD/CAM suite
Tools for marker making, nesting, size grading, pattern editing & corrections
Export-ready patterns compatible with cutting machines
Support, training & software updates along with full CAD/CAM package
Call to Action
Book a Demo / Contact Us
Phone: +91 85955 55373
Email: support@crispincadcam.com
Frequently Asked Questions
Q. Can I generate size-graded patterns automatically?
Yes — the module supports automatic grading across size ranges with accuracy.
Q. Are exported patterns compatible with cutting plotters / CNC cutters?
Absolutely — DXF, PLT, AI, PDF formats are supported for compatibility with industry-standard cutting/plotting machines.
Q. Can I edit patterns manually if needed?
Yes — manual editing, stitch/offset adjustment, seam allowance controls and corrections are supported.
