Description
The GTCO DrawingBoard VI is a professional large-format digitizer designed for engineers, designers, and pattern makers who demand unmatched precision and performance.
This advanced digitizing tablet converts physical drawings, patterns, and templates into accurate digital coordinates for CAD software such as Crispin CADCAM, AutoCAD, and CorelDRAW.
By tracing patterns with a cursor or stylus, the GTCO digitizer accurately captures X-Y coordinates that can be edited, scaled, or used directly for design and manufacturing — eliminating manual tracing errors and improving workflow efficiency.
Key Features
Industry-Leading Resolution & Accuracy
-
Resolution up to 12,700 LPI
-
Standard accuracy: ±0.010″ (±0.254 mm)
-
Optional high-accuracy version: ±0.005″ (±0.127 mm)
-
Repeatability: 1 LSB
Four Digitizer Sizes Available
Choose from four active work areas to suit your application:
-
DB6-2024 — 20 × 24″
-
DB6-2436 — 24 × 36″
-
DB6-3648 — 36 × 48″
-
DB6-4460 — 44 × 60″
Each model features industrial-grade construction, ergonomic design, and lightweight build for precision and portability.
Integrated USB Connectivity
-
Plug-and-play USB connection (no drivers needed for most CAD software)
-
Powered directly via USB – no external power supply required
-
Optional RS-232 serial port available for legacy systems
Choice of Pointing Devices
-
Cordless 4-button cursor
-
Corded or cordless 16-button cursor
-
Corded or cordless click-tip pen with two programmable side buttons
All buttons are fully programmable, improving efficiency and user control.
Convenience & Productivity Features
-
Built-in mounting channel for pen tray and accessories
-
Easy installation with GTCO TabletWorks driver
-
Supports 32 industry-standard output formats
-
Programmable macros (RS-232 mode) for workflow automation
What’s Included
-
✓ GTCO DrawingBoard VI Digitizer (size of your choice)
-
✓ Corded or cordless transducer (cursor/pen)
-
✓ USB cable
-
✓ Pen/cursor tray
-
✓ Mounting brackets (except DB6-2024)
Available Options
Transducer Options
-
Cordless 4-button cursor
-
Corded/cordless 16-button cursor
-
Corded/cordless click-tip pen with two side buttons
Accessories
-
Clear overlay sheet
-
Manual lift/tilt pedestal
-
RS-232 serial kit (with power supply & cable)
Technical Specifications
| Parameter | Specification |
|---|---|
| Platform | PC |
| Drivers | Windows 7 / 8 / 10 |
| Interface | USB & RS-232 |
| Resolution | Up to 12,700 LPI |
| Accuracy | ±0.010″ (Standard) / ±0.005″ (Optional) |
| Repeatability | 1 LSB |
| Proximity (Cordless) | > 0.4 in (10.2 mm) |
| Proximity (Corded) | > 0.8 in (20.3 mm) |
| Data Rate | Up to 200 coordinate pairs/sec |
| Baud Rate | Up to 38,400 |
| Technology | Electromagnetic |
| Output Formats | 32 industry-standard formats |
| Operating Modes | Point, Line, Run, Track, Incremental, Prompt |
| Power (USB) | 5 V DC, 100 mA |
| Power (Serial) | 9 V DC, 200 mA |
| Certifications | UL, EN60950, FCC, CE, VCCI |
Ideal Applications
-
Footwear pattern digitizing for Crispin CADCAM
-
Packaging design and cardboard templates
-
Signage, garment, and automotive design
-
Architecture, mapping, and industrial prototyping
The GTCO DrawingBoard VI is widely used in footwear design, leather industries, and educational institutes across India for high-precision CAD data conversion.
Why Choose GTCO Digitizer
-
Precision-engineered for professional CAD/CAM use
-
Fully compatible with Crispin Software and Autodesk platforms
-
Long-term reliability backed by international certifications
-
Plug-and-play connectivity and minimal maintenance
